Harga Gas Chromatography – Halo labs, gimana kabar anda hari ini? Semoga sehat selalu ya! Artikel “Harga Gas Chromatography” ini merupakan potongan artikel utama tentang instrument Gas Chromatography. Penulis menyarankan pembaca untuk membaca artikel tentang Pengertian GC(Gas Chromatography), jika ingin mempelajar instrument ini, atau membaca artikel versi lengkap pada link berikut : Gas Chromatography. Untuk para pembaca yang lebih ahli atau sering menggunakan alat ini, tolong bantu saran di kolom komentar ya.

kisaran-harga-gas-chromatography-2020

Merupakan hal yang penting jika anda memiliki kebutuhan instrument yang satu ini. Berapa harga gas chromatorgraphy saat ini? Mungkin itu yang sedang ada dipikiran anda saat ini. Maka penulis sampaikan, harga alat gas chromatography tergantung pada merk, spesifikasi dan layanan purna jual. Salah satu merk alat gas chromatography yang memiliki kualitas baik dan hasil yang akurat adalah scion. Link brand tersebut kami sertakan pada link berikut : scion

Lalu bagaimana dengan spesifikasi instrument yang satu ini? Ternyata, perlu anda ketahui alat gas chromatography ini memiliki dua jenis, yakni GC dan GC-MS. Ada beberapa detektor yang perlu anda ketahui, terlebih untuk pengecekan sample anda. Beberapa detektor yang sering digunakan pada instrument ini adalah:

  • FID(Flame Ionization Detector)
  • FPD(Flame Photometric Detector)
  • MS(Mass Spectrometry)

Nah, mulai bingung kan? Supaya anda tidak bingung, penulis berikan contact dimana anda bisa diskusi dengan product specialist via WhatsApp : +6287777277740 atau Telepon (0251) 7504679. Link produk kami sertakan disini : Jual Gas Chromatography

Oke, kita lanjutkan ke spesifikasi alat gas chromatography. Semoga dengan mengetahui spek ini, anda jadi memiliki gambaran bagaimana spek yang sesuai untuk kebutuhan anda.

Spesifikasi Gas Chromatography GC-436

gc-436-gas-chromatography-pt-andaru-persada-mandiri-distributor-alat-laboratorium

Overview :

The perfect GC for many applications that saves space without compromise on functionality and performance. Capacity for 2 injectors , 1 GC detector plus a mass spectrometer makes the SCION 436 a perfect match for your analyses. A 9 inch touchpad provides direct access to all GC functions and basic tuning.

Highlight :

  • Compact footprint
  • Fast ramping oven (170°C/minute)
  • Flexible 2 channel architecture
  • 2 Injectors, 1 Detectors + MS
  • Electronic flow control (EFC), 3 channels 0.001psi resolution
  • Large full colour screen, multiple languages supported
  • Full automation capabilities through CompassCDS software and auto sampler

Dimensions and Weights

Height*: 57 cm (22.5 in.),
Width: 32 cm (13.0 in.),
Depth: 61 cm (24.0 in.)
Weight*: 26.8 kg (59lb)
* Typical values

Environmental Conditions

Operating temperatures: 10°C to 40°C.
Operating humidity (relative): 5 % to 95 %
Line voltage requirements: 120 V, 230 V (±10 % nominal)

Column Oven

Dimensions: 23 cm (w) x 11 cm (d) x 28 cm (h)
Temperature range:

  • Ambient: +4°C to 450°C
  • Liquid N2: -100°C to 450°C
  • Liquid CO2: -60°C to 450°C

Temperature program ramps/holds: 24/25
Maximum temperature ramp rate: 170°C/min for all voltages

Cool down rate: 400 °C to 50 °C in 4.5 minutes
Temperature set-point resolution: 0.1 °C
Ambient temperature reject <0.01°C change in oven for 1°C change in ambient temp.
Retention Time Repeatability <0.008% or < 0.0008 min, based on n-Pentadecane under temperature programming conditions.
Area repeatability < 1% RSD

General Specifications

Up to 3 EFC modules total, injector, detector and auxiliary
Optional backflush
GC Control:
External events (digital output):

  • 8 standard
  • 8 optional, total 16

Max number of timed events: 30 #
Heated zones:

  •  Standard 5

Two power outlets 24V (1A max. each)

Methods:

  • Maximum stored internal methods: 50 (max. 30 alphanumeric characters)

Logging:

  • Run log file (stored with the chromatogram when using CompassCDS)
  • Error log file

Local Display:

  • TFT full color screen
  • WVGA resolution (800 x 480); size 23 cm (9”)

Local Control:

  • Touch screen
  • Hard Keys

Languages:

  • English, German, French, Spanish, Italian, Portuguese, Cyrillic, Kanji, Chinese (standard and traditional), Thai, Korean
  • and Dutch

Local automation:

  • Method lines: 25
  • Modes: (Infinite looping, Dual and duplicate injection)

Communication

Ethernet: Protocol: TCP/IP Data rate: 100 Mbps
Control:

  • GC control and method parameters
  • Analog output (optional): (Number of channels: 1, Time programmable steps: 30)
  • Output software selectable (set individual): (0-1 V (default), 0-10 V)

Synchronization signals with other devices and data systems:
Ready in and out
Start in and out

Data Handling and System Control:
CompassCDS Chromatography Data System

Certifications

  • CSA: C22.2 61010-1,UL 61010-1, IEC: 61010-1
  • EMC: 47 CFR part 15, ANSI C63.4, EN 61326
  • ATEX Directive 94/9/EC

Injector Options

Maximum injectors: two, operating concurrently
Pneumatics: Electronic Flow Control (EFC)
Injector types:

  • S/SL Split/Splitless injector*
  • PTV Programmable Temperature Vaporizing*
  • COC Cold On-Column injector*
  • Flash injector
  • PWC Packed/ Wide bore On-Column injector

* including septum purge

S/SL Split/Splitless Injector

Pressure range: 0-150 psi
Total flow:

  • 500 mL/min for N2/Ar
  • 1500 mL/min for He/H2

Maximum temperature: 450°C
Split range: 1-10,000 (column dependent)

Suited for columns:

  • Wide bore: (0.53 mm)
  • Narrow bore: (0.05 to 0.32 mm

COC Cold On-Column Injector

Pressure range: 0-150 psi
Total Flow: 50 mL/min (Type 23 EFC)

Temperature range:

  • Ambient +10 °C to 450 °C using air cooling
  • -60 °C to 450 °C using liquid CO2 cooling
  • -160 °C to 450 °C using liquid N2 cooling

Maximum temperature: 450°C
Maximum temperature ramp rate: 200°C/min
Temperature ramps/holds: 24/25

Suited for columns:

  • Wide bore (0.53 mm)
  • Narrow bore

PTV Programmable Temperature

Vaporizing Injector
Pressure range: 0-150 psi
Total flow:

  • 500 mL/min for N2/Ar
  • 1500 mL/min for He/H2

Temperature range:

  • Ambient + 10 °C to 450°C using air cooling
  • -160 °C to 450 °C using liquid N2 cooling
  • -60 °C to 450 °C using liquid CO2 cooling

Maximum temperature ramp rate: 200°C/min
Temperature ramps/holds: 24/25
Split range: 1-10,000 (column dependent)

Operational capabilities:

  • Large volume injection
  • Temperature ramped splitless
  • Cold on-column
  • Split and splitless

Suited for columns:

  • Wide bore (0.53 mm)
  • Narrow bore (0.05 to 0.32 mm)
  • Maximum injection volume: 250 µL (LVI mode)

Flash Injector

Pressure range: 0-150 psi

  • Total flow: 50 mL/min (Type 23 EFC)

Maximum temperature: 450°C

Suited for columns:

  • Wide bore (0.53 mm)
  • Packed (1/8” to 1/4”)

PWOC Packed/Wide-bore On-Column Injector

Pressure range: 0-150 psi

  • Total flow: 50 mL/min (Type 23 EFC)

Maximum temperature: 450°C
Suited for columns:

  • Wide bore (0.53 mm)
  • Packed (1/8” to 1/4”)

Electronic Flow Control: Injectors (EFC)

Module types: 2 injector-specific modules
Pressure: 0.1 % Full Scale
Resolution pressure set points is 0.001psi
Flow sensor accuracy 2% of measured or 0.2% of full scale Flow sensor repeatability 0.5%

Detector Options

Maximum detectors : two, operating concurrently.

Pneumatics: Electronic Flow Control (DEFC)

Detector types:

  • FID Flame Ionization Detector
  • TCD Thermal Conductivity Detector
  • ECD Electron Capture Detector NPD
  • NPD Nitrogen-Phosphorus Detector
  • PFPD Pulsed Flame Photometric Detector
  • PDHID Pulsed Discharge Helium Ionization Detector
  • MS Mass Spectrometry (see GC/MS brochure and datasheet)

Note: Data Acquisition Rate: 600Hz for all detectors,
(exception PFPD)

FID Flame Ionization Detector

Maximum temperature: 450 °C

  • Detectivity: 1.4 pg C/sec
  • Linear dynamic range: 10 7

Flame tip type: ceramic (patented)
Operational quality:

  • Flame-out detection
  • Auto re-ignition

TCD Thermal Conductivity Detector

Maximum temperature: 450 °C
Detectivity: 300 pg/mL (Butane)
Linear dynamic range: 10 6

Operational quality:

  • Filament protection
  • Automatic bridge balancing

ECD Electron Capture Detector

Maximum temperature: 450 °C
Detectivity: 7 fg/s Lindane
Linear dynamic range: 10 4
Radioactive source: 63Ni – 15 mCi (555 Mbq)

NPD Nitrogen-Phosphorus Detector

Maximum temperature: 450°C
Detectivity:
N: 100 fg N/sec (Azobenzene) P: 100 fg P/sec (Malathion)

Linear dynamic range:

  • N: 10 5
  • P: 10 4

PFPD Pulsed Flame Photometric Detect

Photomultiplier tube: S/P

  • S/P/N

Maximum temperature: 450 °C

Detectivity:

  • S: 1 pg S/sec (S/P tube)
  • P: 100 fg P/sec (S/P tube)
  • N: 20 pg N/sec (S/P/N tube)

Linear dynamic range:

  • S: 10 3
  • P: 10 4
  • N: 102
  • Up to 23 elements can be detected

PDHID Pulsed Discharge Helium Ionization Detector Detectivity:

50 ppb (Methane)
Linear dynamic range: 104
(Methane)
Operational quality:

  • Gold plated connections
  • Welded column connections

Detectors (DEFC)

Module types: 6 detector-specific modules
Accuracy: ± 7 % set point flow
Resolution: 0.1 or 1 mL/min

Automation Options

8410 Auto injector

Sample capacity:

  • 10 x 2 mL vials
  • 6 x 5 mL vials
  • 5 x 10 mL vials

Large solvent wash vial: 2 x 120 mL*
Dual and duplicate mode
Internal standard addition

Modes of operation:

  • Liquid
  • Ambient headspace*
  • SPME (Solid Phase Micro Extraction)*
  • Sample heating and cooling*

Pre-programmed modes of injection Syringes:

  • 1 μL, 2 μL, 5 μL, 10 μL, 100 μL, 250 μL for liquid injection
  • SPME

8400 Autosampler

Sample capacity: 100 x 2 mL vials
Large solvent wash vial: 2 x 120
mL* Dual and duplicate mode
Internal standard addition

Modes of operation:

  • Liquid
  • Ambient headspace*
  • SPME*
  • Sample heating and cooling*
  • Pre-programmed modes of injection

Syringes:

  • 1μL, 2 μL,5 μL,10 μL,100 μL,250 μL for liquid injection
  • SPME

* Optional
Optionally a CTC-PAL autosampler, including specific options
may be installed.

Bagaimana dengan spesifikasi alat gas chromatography tersebut? Bagi beberapa orang yang belum terbiasa dengan instrument tersebut atau teknisi laboratorium, mungkin akan kebingunan dengan hal tersebut. Beberapa link spesifikasi instrument gas chromatography lainnya, saya sertakan pada link berikut :

Oke, kita masuk lagi ke pembahasan tentang harga gas chromatography. Harga gas chromatography mungkin saja naik ataupun turun sesuai dengan perkembangan waktu. Adapun kisaran harga gas chromatograpy (GC) berada di kisaran 1 miliar. Sedangkan kisaran harga gas chromatography mass spectrometry (GC-MS) berada di kisaran 2,6 miliar. Harga ini tentu memiliki syarat dan ketentuan. Misal, harga tersebut sudah termasuk konsultasi sebelum pembelian, ongkos kirim, training penggunaan awal, garansi dan maintenance. Pastikan anda mendapat penawaran harga gas chromatography yang paling kompetitif.

Semoga pembahasan mengenai harga gas chromatography ini bisa memberikan informasi kepada anda terkait kisaran harga gas chromatography. Jika anda memiliki kebutuhan alat instrument gas chromatography, silahkan hubungi PT. Andaru Persada Mandiri sebagai distributor alat laboratorium. Anda bisa menghubungi kami via WhatsApp : +6287777277740 atau Telepon (0251) 7504679 ke office kami. Sekian dan tentu saja terima kasih.
